Galvanized Steel Strand Wire

T-SW001 Series Steel Strand mainly used in Reinforcements and tensioning materials for optical fiber cables, cables and overhead ground wires. It has Galvanization Smooth surface.

Categories , ,
Inquiry

T-SW001 Series Steel Strand Wire Galvanized

Diameter:8.0-16.0mm
Application: Reinforcements and tensioning materials for optical fiber cables, cables and overhead ground wires
Surface Coating: Galvanization Smooth surface
Parking Type: Spool
Characteristic:
1.Fixed size steel wire production
2.The surface is clean,no oil stain
3.According to YB,EN,ISO,JIS,ASTM,etc.,can also be produced, or customer’s technical requirements

Steel Wire Galvanized Technology Parameter

Nominal Diameter Approcimate Weight Nominal Tensile Strength(Mpa)
1870 1960 2060 2160 2260 2360
d Allowable Deviation Minimum Breaking Tension,KN
mm % kg/100m KN
8 -5 24.3 41 43 45.2 47.4 49.6 51.8
8.3 -2~+3 36.4 44.2 46.3 48.7 51 53.4 55.8
8.6 -2~+3 28.3 47.1 49.3 51.9 54.4 56.9 59.4
9 -2~+3 32 51.3 53.8 56.5 59.3 62 64.8
9.5 -5 35.5 57.3 60.1 63.1 66.2 69.3 72.3
10 -2~+3 39 63.6 66.7 70.1 73.5 76.9 80.3
11 -5 47.2 47.2 80.6 84.7 88.9 93 97.1
12 -2~+3 56.2 56.2 96 101 106 711 116
14 -5 76.4 76.4 131 137 144 151 157
16 -2~+3 99.8 99.8 171 179 188 197 205
*Note: According to customer requirements, We can also provide other specifications, Tensile strength products.
Remarks during use and handing :

  • In the process of transportation, it should be lifted and put gently to prevent the impact from damaging the outer package. It is moisture-proof and strictly prohibited to get wet. The wire rope should be stored in a dry and ventilated room.
  • On the shaft production should pay attention to the direction of twist and line direction. And pay attention to the consistency of the spool freely selection and tension.
  • The remaining steel strand must be rewrapped in time to prevent the surface oxidation. And deterioration of the steel strand due to the classification of the preparation (use).
*All products can be customized according to your required parameters
