2-24 Core Double Sided Plastic Coated Armored Directly Burial Underwater Cable
Directly Burial Underwater Cable can withstand disasters such as seawater erosion and marine earthquakes. It has high stability and reliability. In order to meet the needs of international voice calls. The transmission speed of underwater optical cables is generally very high. It can transmit tens of TBS of data per second. Another feature of underwater optical cables is that they are highly concealed and are not easily intercepted or interfered with.
Feature
- Double Armored and Double Sheath Underwater Directly Burial Optical Cable (GYTA33);
- Single mode (9/125); Multimode (62.5/125, 50/125);
- Product length can be customized according to customer needs;
- Double sided plastic coated aluminum tape – polyethylene bonded sheath, excellent moisture resistance;
- Round and thin steel wire armor, greatly improving tensile, flattening, and impact resistance performance;
Application
1.Long distance communication and inter office communication;
2.Suitable for various harsh environmental conditions such as steep slopes and river crossings;
Characteristic and Performance
Cable Cores No. | Outer Dia. | Cable Weight | Minimum bending radius | Allow tension(N) | Allow lateral pressure(N/100MM) | |||
Static | Dynamic | Short term | Long term | Short term | Long term | |||
2-24 | 15 | 400 | 12.5 times the outer diameter of the optical cable | 25 times the outer diameter of the optical cable | 20000 | 10000 | 5000 | 3000 |
26-36 | 15 | 400 | 20000 | 10000 | 5000 | 3000 | ||
38-60 | 17 | 400 | 20000 | 10000 | 5000 | 3000 |
Packaging: Standard disc tools
