The structure of No.T-FC102 GYTZA armored flame retardant optical cable is to insert 250 µm optical fiber into a loose tube made of high modulus material, and fill the loose tube with waterproof compound. The center of the cable core is a metal reinforced core, and for certain numbers of optical cables, a layer of polyethylene (PE) needs to be extruded outside the metal reinforced core. The loose tube (and filler) is twisted around the center to form a compact and circular cable core, and the gaps inside the cable core are filled with waterproof fillers. Plastic coated aluminum strip (APL) is longitudinally wrapped and extruded into a flame-retardant sheath to form a cable.

Performance Standard

Meet YD/T 1114;

Applition

• For outdoor and indoor use in structured (data) wiring systems such as campus backbone;
• Armored flame retardant optical cable is suitable for outdoor and indoor use in networks for telecom, cable TV and/or broadcast;
• Outdoor Fiber Optic Easy to install in ducts, tunnels and trenches by means of compressed air or pulling wire;
• Suitable for direct burial Features & Benefits;
• pipelines, overhead

Feature

1.Has excellent mechanical properties and temperature characteristics;
2.The loose tube material itself has good hydrolysis resistance and high strength;
3.The tube is filled with special ointment to provide critical protection for the optical fiber;
4.Specially designed compact fiber optic cable structure effectively prevents sleeve retraction;
5.Armored flame retardant optical cable has good compression resistance and flexibility;
6.Special sheaths have excellent flame retardant properties;
7.Take the following measures to ensure the waterproof performance of the optical cable:
-Single steel wire center reinforcement core
-Filling special waterproof compounds inside the loose tube
-Complete cable core filling
-Plastic coated aluminum strip (APL) moisture-proof layer

Specification

Storage,Working Temperature: -40ºC~+70ºC
